This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Equipped With
- HMI 15" Color LCD Touch Screen
- Windows Embedded Standard (Wes)
- Nozzle Tip Cooling
- IPG Solid-State Fiber Laser
- Lightweight Aluminum Honeycomb Gantry
- A/C Brushless Permanent-Magnet Linear Servo Motors
- High Resolution Open Style Linear Coders
- Breakaway Non-Contact Autofocus Laser Head
- 7.5" Focal Length Lens
- Edge of Sheet Detection
- CNC Programmable High Pressure Assist Gas
- Box Cutting (Lower Pallet Special Function)
- Dual Pallet Cutting Tables
- Recirculating Water-Cooling System
- Cutting Area Enclosure
Specifications
- Control Meldas 500 Series
- Power Output 4000 Watt
- Type Fiber
- Table Size L 60" x W 120”
- X-Axis Travel 14.3"
- Y-Axis Travel 27.6"
- Z-Axis Travel 43.5"
- Rapid Traverse Jog (X And Y Axis) 1200 Ipm
- Rapid Traverse Jog (Z Axis) 1700 Ipm
- Positioning speed 12,000 Ipm
- Polarization Random
- Microprocessor Multi-Processor
- Pulse Frequency 8 - 5000 Hz
- Lens Focal Length 7.5"
- Beam Quality 50 Micron Feeding Fiber
- Modes Of Operation Continuous Wave, Quasi-Continuous Wave
- Nozzle Cooling Purge Compressed Air Filter/Dryer
- Compressed air supply 480 Scfm @ 80 To 140 Psig
- Absolute Positioning X & Y Axis +/- 0.001"
- Rapid Traverse (Z Axis) 1,700 Ipm
- Repeatability X & Y Axis .001"
- Normal Jog (X And Y Axis) 300 IPM
- Rapid Traverse (X/Y) Simultaneous 12,020 IPM
- Accelerations X And Y Axis 1.65 G
- Accelerations Z-Axis 2.00 G
- Cutting Capacities - Oxygen 10 Ga. To 1/2"
- Cutting Capacities - Nitrogen 20 Ga. To 1/4"
- Assist Gas Pressure Adjustment 5 - 400 PSI
- Voltage 460v ~ 3 Phase
Machine Description
No description available
