This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Equipped With
- Fanuc Oi Mate TD Control
- 16 Automatic Tool Changer
- Aprox. 6 tool holders
Specifications
- Spindle Motor (HP) 45 HP
- Max Swing (inches) 17.32"
- Maximum Swing Diameter 78.74"
- Maximum Turning Diameter 74.80"
- Travel of Rail Head (Vertical) 39.37"
- Travel of Rail Head (Horizontal) 78.74"
- Raid Feed of Rail Head (Vertical) 157 IPM
- Raid Feed of Rail Head (Horizontal) 236 IPM
- Range of Railhead Feed 1 – 7.87 IPM
- Worktable Diameter 62.99"
- Speed Range of Worktable 220 RPM
- Tool Changer Type 60 ATC
- Tool Holder BT 50
- Maximum Tool Weight 33 lbs.
- Maximum Tool Length 3.94"
- Maximum Weight of Workpiece 17,600 lbs.
- Resonator ( Type ) 55
- Spindle Taper (CAT/BT) HSK-463
- Spindle Speed 12,000 RPM
- Bar Stock Capacity 2.0"
- V-Axis Travel 5555
- Vertical Travel of Ram 4444
- Wire Diameter (inches) 3333
- Wire Traveling Speed 22
- Pallet Size (inches) 25"
- Z - Axis Travel (inches) 14.7" / 375mm
- Y - Axis Travel (inches) 15.7" / 400mm
- X - Axis Travel (inches) 15.7" / 400mm
- Turret Capacity 8 Positions
- Table Size - L 61"
- Table Size - W 30"
- Throat Depth 9.45"
- Chuck Size (Inches) 8"
Machine Description
Specifications:
Max. Turning Diameter 74.80”
Max. Swing Diameter 78.74”
Worktable Diameter 62.99”
Max. Weight of Workpiece 17,600 lbs.
Speed Range of of Worktable 220 RPM
Travel of Rail head:
Horizontal 78.74”
Vertical 39.37”
Magazine Capacity 16 ATC
Tool Holder BT 50
Max. Tool Weight 33 lbs.
Max. Tool Length 3.94”
Range of Railhead Feed 1 – 7.87 IPM
Raid Feed of Railhead:
Horizontal 236 IPM
Vertical 157 IPM
Power of Main Motor 45 HP
Weight of Machine 44,000 lbs.
Overall Dimensions 236” x 181” x 169
