This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Equipped With
Specifications
- Spindle Speed 12,000 RPM
- Chuck Size (Inches) 8"
- Tool Changer Type 60 ATC
- Max Swing (inches) 17.32"
- X - Axis Travel (inches) 15.7" / 400mm
- Y - Axis Travel (inches) 15.7" / 400mm
- Z - Axis Travel (inches) 14.7" / 375mm
- Pallet Size (inches) 25"
Machine Description
X- Axis Travel 21.7" (550mm)
Y-Axis Travel 15.7" (400mm)
Z-Axis Travel 16.3" (415mm)
Distance between Table Top and Spindle Nose End 25.4" (654mm)
Work Area Size 23.6" x 16.7"
Max Loading Capacity (Uniform Load): 441 lbs
Max Turning Diameter 47.2"
Table Positioning Time 3.4 sec/180°
Table Change Repeatability 0.0004"
Spindle Speed Range 16 - 16,000RPM
Speed during Tapping 8,000RPM
Rapid Traverse Rate (X/Y/Z) 2,756"
Cutting Traverse Rate 0.04 - 787.4" (inch/min)
Tool Storage Capacity 18 (+1) / 26 (+1)
Position Accuracy 0.0002 / 11.8"
Repeatability ± 0.00012"
