This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Equipped With
- HRT160 Rotary
- 4th-Axis Drive and Wiring
- Convenience Package
- Extended Warranty (3/2020)
- 1GB Memory
- Coolant Pump Kit 1/4 hp
- Ethernet Interface
- Haas Connect Option
- Media Display M-Code
- Rigid Tapping
- Haas Window Blast
- Work Light
Specifications
- X - Axis Travel (inches) 15.7" / 400mm
- Y - Axis Travel (inches) 15.7" / 400mm
- Z - Axis Travel (inches) 14.7" / 375mm
- Max Cutting Speed (IPM) 833
- Spindle Taper (CAT/BT) HSK-463
- Spindle Nose to Table (Max) 18"
- Spindle Nose to Table (Min) 4"
- Max Rating 15 HP
- Max Speed 10,000 RPM
- Max Torque 17 ft-lbf @ 4600 rpm
- Bearing Lubrication Air / Oil Injection
- Length 40"
- Width 14"
- T-Slot Width 0.630"
- T-Slot Center Distance 4.90"
- Number of STD T-Slots 3
- Max Weight on Table (evenly distributed) 500 lb
- Rapids on X 1,200 IPM
- Rapids on Y 1,200 IPM
- Rapids on Z 1,200 IPM
- Max Thrust X 2000 lbf
- Max thrust Y 2000 lbf
- Max Thrust Z 2000 lbf
- Capacity 20
- Max Tool Diameter 3.5"
- Max Tool Weight 12 lb
- Tool-to-Tool (avg) 4.2 S
- Chip-to-Chip (avg) 4.5 S
- Coolant Capacity 40 Gal
- Air Required 4 SCFM@ 100 PSI
- Inline Air Hose 3/8"
- Coupler (Air) 3/8"
- Air Pressure Min 80 PSI
- Input AC Voltage (3 Phase) Low 220 VAC
- Full Load Amps (3 Phase) Low 40 A
- Input AC Voltage (3 Phase) High 440 VAC
- Full Load Amps (3 Phase) High 20 A
Machine Description
No description available
