Haas VF-3 2002

TRAVELS: --X: 40" --Y: 20" --Z: 25" SPINDLE NOSE TO TABLE (~ MIN): 4.5” SPINDLE NOSE TO TABLE (~ MAX): 29.5” TABLE: LENGTH: 54” WIDTH: 25” T-SLOT WIDTH: 5/8” T-SLOT CENTER DISTANCE: 3.15” NUMBER OF STD T-SLOTS: 5 MAX WEIGHT ON TABLE: 3500 LB SPINDLE: MAX RATING: 30HP MAX SPEED: 10,000 RPM MAX TORQUE: 75 FT-LB @1400 RPM DRIVE SYSTEM: 2 SPEED GEARBOX MAX TORQUE W/OPT GEARBOX: 250 FT-LB @ 450 RPM TAPER: CT 40 BEARING LUBRICATION: AIR/OIL INJECTION COOLING: LIQUID COOLED FEEDRATES: RAPIDS ON X: 710 IN/MIN RAPIDS ON Y: 710 IN/MIN RAPIDS ON Z: 710 IN/MIN MAX CUTTING: 500 IN/MIN AXIS MOTORS: MAX THRUST X: 2550 LB MAX THRUST Y: 2550 LB MAX THRUST Z: 4200 LB GENERAL: AIR REQUIRED: 4 SCFM, 100 PSI COOLANT CAPACITY: 55 GAL POWER: 195-260 VAC/50 A 354-488 VAC/30 A MACHINE WEIGHT: 14000 LB
