This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Equipped With
- New Cost $136600
- Only 1800 Cutting Hours
- Purchased 12/21
- Put into Service 1/22
- V350-V AEII Power Supply with Digital Spark Control
- DMX-S (Digital Matrix Sensor) Shapes each spark reducing electrode wear
- Non-contact
- Zero Back-Lash Linear Shaft Drive System XYUV (no ball screws)
- All Fiber Optic servo control (4X faster internal communication speed)
- Submerged Machining to 8.7″ Deep
- Automatic Fluid Level Control
- Automatic Vertical Machine Tank Door
- One Piece Hardened 4-Sided Stainless Work Table
- Fine Grain “Dianite” Casting Material
- Split Axis Construction (Table Moves in X
- Column Moves in Y)
- Windows 8 Embedded Operating System
- CFAST Compact Flash Card memory with 1GB user program storage
- Fully-Automatic Rough Machining Control covers PM
- CM-R and EM functions
- Program Input Methods Keyboard
- USB Flash Memory
- and Ethernet with FTP
- DC-Servo (Closed Loop) Torque Control Wire Tensioning System
- Linear Motion Guide Ways
- All-Axes Absolute Control System
- Linear Glass Scale Feedback (X-Y-U-V Axes)
- Optical Rotary Encoder Feedback (Z-Axis)
- Auto-Threading with Scrap Wire Processor (Chopper)
- New 14″ AT Annealing Length Improves Threading Reliability
- Inverter Controlled 16-Step Programmable Flushing
- Full Time AEII (Anti-Electrolysis) Power Supply Protection
- Dielectric Fluid Chiller
Specifications
- Travels 15.7 x 11.8 x 8.7"
- Maximum Workpiece Dimensions 31.9 x 27.6 x 8.5"
- Table Dimensions 25.2 x 21.3"
- Max. Submerged Workpiece Weight 102lbs
- U/V Travels (from center) ±2.4 x ±2.4"
- Taper Angle @ Thickness: 15 deg.@ 8.0"
- Table Rapid Feed Speed 51.2in/min
- Wire Diameter Possible 0.004~0.012"
- Minimum Start Hole Diameter 0.02"
